Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply

Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply

  • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
  • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
  • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
  • Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply
Ürün ayrıntıları:
Place of Origin: China
Marka adı: LABWE multi-Touch Interactive Whiteboard,low cost classroom white board
Sertifika: ISO 9001, CE, FCC, ISO14001 (environment certificate), RoHS
Model Number: LWB-5401
Sample policy:: sample is available for multi-Touch Interactive Whiteboard,low cost classroom white board
Ödeme & teslimat koşulları:
Minimum Order Quantity: 1 Piece/Pieces
Packaging Details: CARTONS ( wooden can be available if in special amount and requirement)
Delivery Time: 7 days after payment
Payment Terms: T/T
Supply Ability: 300 PCS/DAY
İletişim
Detaylı ürün tanımı
Cursor blink rate: 120 Dots/Second HDD: 1GB free space
Memory: 256MB RAM PC Interface: USB2.0
Operating: touch, writing, mark, interactive, smart
Vurgulamak:

touch screen Interactive Whiteboard

,

education Interactive Whiteboard



Meeting and School Multi-Touch Interactive Whiteboard with USB Power Supply



Model:LWB-5401

Physical Size: 54 inches

Effective Size: 47.4 inches

Phase Ratio: 4:3

Effective Response Area: 1006mm X 680mm, Effective Writing Area: 978mm X 652mm

Physical Dimensions: 946mm X 1271mm X 82mm

Shortcuts: Right

Net Weight: 8 kg

Gross Weight: 13 kg



multi-Touch Interactive Whiteboard,low cost classroom white board Specification



multi-Touch Interactive Whiteboard,low cost classroom white board Harware Features



1) Whiteboard material: Imported PET material, matt surface

2) Screen surface: The hard-coated steel surface is durable, optimized for projection, compatible with dry-erase markers and easily cleaned with whiteboard cleaner. Green, Environmentally friendly.

3) PCB finish: All the electronic parts are finished by SMT, therefore, the PCB looks clean and tidy and functions stably.

4) Wall-mount bracket: Four M8 screws and toggle bolt anchors (two upper/ lower frame, adjustable) to support a wall-mounted interactive whiteboard.

5) Portable stand: Available for different sized interactive whiteboard

6) Computer connection: 16' (5 m) USB 2.0 cable, Plug and play, no need to install driver or server to run the whiteboard.

7) Power requirements : Power consumption is less than 7 W (USB 5V voltage, current < 100mA).

8) Plug and Play, no need to install driver



multi-Touch Interactive Whiteboard,low cost classroom white board Software Features

1) Touch and gesture: Perform mouse functions with your finger: to write, click and right click. Recognize guestures: fist gesture to earase, two fingers(one hand) touch to move and two fingers (two hands) touch to zoom in and out of images.
2) Resolution: Touch resolution is 8192 × 8192
3) Smooth writing, without any breakpoint or sharp curve
4) Compatible with Win, Mac OS, Linux and Android
5) Interaction functions: To use any type of computer and projector to make up interactive e-educational environment
6) Short cuts on both sides of the whiteboard, convenient to operate.
7) PPT import and editable.
8) Save Interactive whiteboard data as Doc., Picture, PDF, HTML, PPT, etc.
9) Whiteboard data can be printed
10) For modes(Teaching mode, Annotation mode, Design mode, Control Mode) satisfy different needs.
11) Insert function: Insert Table, Function, Image, Video, Audio, Flash, Text, Link, Lines, Shapes, etc.
12) Multi-tools: Different kinds of tools to choose from including Pens, Erasers, Sportlight, Curtain, Clock, Keyboard, Camera, Video/Audio recorder, Magnify, etc.
13) Math tools: Including Calculator, Ruler, Compasses, Set square, Protractor, etc.
14) External tool: Allow you to add any EXE. File to the whiteboard to achieve interactive environment.
15) Resource library: Abount teaching resources, you can also add by yourself, convenient for teaching.

Technical Specifications for multi-Touch Interactive Whiteboard,low cost classroom white board

Touch Features
 Operating Principle: Infrared Induction Technology
 Positioning Accuracy: <2mm
 Cursor Blink Rate: 120 Dots/Second
 Resolution: 8192 × 8192
 Response Time: < 8ms in continuous writing practice
 I nduction Size: > 3.0mm, Recommended Size:> 5.0mm (Diameter)
 T ouch Spot Life Span: Over 60,000,000 times single spot touch

Working Environment

 Power Supply: USB power supply (No external power supply needed)
 Operating Voltage: DC 4.6V ~ DC 5V
 Power Consumption: <1W, USB 5V voltage, current < 100mA
 CPU: X86-based processor, pentium III or above;
 Memory: 256MB RAM (512MB RAM recommended);
 HDD: 1GB free space;
 USB: At least a spare USB interface;
 Projection Equipment: Normal projector compatible.
 Operating Temperature: -10 °C to 45 °C
 Operating Humidity: 20% to 85%
 Light Test: Incandescent (220V, 100W), working distance: 350mm
 Altitude: 3,000 meters or below
 PC Interface: USB2.0
 Working Life: 5 years or above
 Work Environment: Under daylight, indoor & outdoor environment.

Packing List

Standard Accessories
 LABWE (Infrared) Electronic Blackboard: 1
 Normal ink pen markable: 3
 USB cable (5 Meters, Blue): 1
 Installation Software Disk: 1
 User's Manual: 1
 Service Card: 1
 Wall-mounting Parts: 1
 Screws (ST4 * 30mm KA): 8
 Plastic Gecko (6 * 29mm): 8

Optional Accessories

 Mobile Stand: 1set
 USB Extension HUB Cable (5 Meters, Silver): 1 piece

Application:

Labwe multi-Touch Interactive Whiteboard,low cost classroom white board adopts Infrared Technology, finger touch sensitive. Widely used for schools, whiteboard classroom , conference, military and many other occasions.



Advantages:

Plug and Play

SMT Technology

CE/FCC/ROHS certified

Multi languages

Available on Windows/Linux/Mac/Android system

Professional Technical Support

3 years warranty

Easy maintenance

Factory price

40 minutes to Shenzhen port, fast delivry





Packing & Shipping for multi-Touch Interactive Whiteboard,low cost classroom white board



Samples usually packed in cartons with wooden cases, for bulk quantities, goods usually shipping by sea with containers.



Our services



Samples are accepted, and will be deliveried within 7 working days. OEM/ODM services are welcomed. We offer online support 24/7, 3 years waranty for all our products.


Function:

usb support,finger writing,infrared,mounted on wall,portable,mobile,moveable,short throw projector,usb port,all in one,anti-scratch,markable,multi point touch, gestures recognition,32 point,64 point,10 point,dual writing ,IR,wall hang,easy taking


Description:

smart active board for Schools

LABWE (Infrared) interactive whiteboard , is a large interactive display that connects to a computer. A projector projects the computer's desktop onto the board's surface where users control the computer using a pen, finger, stylus, or other device. The board is typically mounted to a wall or floor stand.
They are used in a variety of settings, including classrooms at all levels of education, in corporate board rooms and work groups, in training rooms for professional sports coaching, in broadcasting studios, and others.


smart active board adopts Infrared Technology, finger touch sensitive.



Certification: ISO 9001, CE, FCC, ISO14001 (environment certificate), RoHS
